Style B rectangular connector

Diode

CF - CF11 05A00

CF - CF11 05A00

Avez-vous des questions sur ce produit?

Contactez notre spécialiste du connecteur

Envoyez-moi une offre personnalisée

Télécharger la fiche produit

Plus d’infos sur cette marque:

Housing Material

PUR
TPR

Article Number	CF14 05A00 414 3000 0
Protection Degree	IP65*
Upper Temperature	+70 °C
Lower Temperature	-40 °C
Contact Type	Fork
Circuits	Diode
Housing Oil Resistance	Very good
Housing Hardness	90 shore A
Other Characteristics	M3 central screw material: zinc plated iron
Voltage Vdc	1 to 250
Max. Currrent	10 A @40°C
Clamping Voltage	-1 V
Housing Colour	Black
Remark*	The IP65 protection degree is valid only if the connector is mounted with the cable exit not upward

Article Number	CF11 05A00 414 3000 0
Protection Degree	IP65*
Upper Temperature	+70 °C
Lower Temperature	-40 °C
Contact Type	Fork
Circuits	Diode
Housing Oil Resistance	Occasional contact
Housing Hardness	73 shore A
Other Characteristics	M3 central screw material: zinc plated iron
Voltage Vdc	1 to 250
Max. Currrent	10 A @40°C
Clamping Voltage	-1 V
Housing Colour	Black
Remark*	The IP65 protection degree is valid only if the connector is mounted with the cable exit not upward

Les propriétés diffèrent selon les variantes et sous-variantes
