Screw Terminals / Binding Posts
Haben Sie Fragen zu diesem Produkt?
Weitere Informationen über diese Marke:
Zierick
Zierick
Screw Type
- 1/4" (6.35mm) x 6-32 Torx Head Screw
- Stainless Steel Binding Head 1/4" (6.35mm) x 6-32
| Article Number | 1108 | 1108-GRSC* |
| Remark | / | GRSC = green screw indicates it is a grounding screw |
| Packaging | Loose | Loose |
| Material Thickness / Type | 0.032" (0.81mm) C26000 Brass | 0.032" (0.81mm) C26000 Brass |
| Standard Finish | 100% Tin over Copper | 100% Tin over Copper |
| Current Rating | 30 Amperes | 30 Amperes |
| Screw Position | Inserted, Staked and Down | Inserted, Staked and Down |
| Pieces Per Reel (loose Part No.) | NA | NA |
| Pieces Per Reel (taped Part No.) | / | / |
| Datenblatt | / | / |
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
