SMT Insulation Displacement Connectors

Packaging

  • Loose
  • Reeled
Article Number 1227
Material Thickness / Type 0.032" (0.81mm) C26000 Brass
Standard Finish 100% Tin over Copper
Current Rating 20 Amperes
Feeder System Surf-Shooter SMT ™ Continuous Strip Feeder
Wire Gauge Range #26-18 AWG Wire insertion tool required.
Pieces Per Reel (loose Part No.) NA
Pieces Per Reel (reeled Part No.) /
Datenblatt Download Datenblatt
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
