SMT Dual Entry Box Receptacle

Packaging

  • Loose
  • Reeled
  • Taped
Article Number 1266
Mating Terminal Size 0.020" (0.51mm) to 0.025" (0.64mm) thick
Material Thickness / Type 0.008" (0.20mm) C51000 Phosphor Bronze
Standard Finish 100% Tin over Copper
Current Rating Ul 12 Amperes
Current Rating C-ul 12 Amperes
Feeder System Surf-Shooter SMT ™ Continuous Strip Feeder Standard 16mm Tape Feeder for PNs 1266-TV and 1266-TV-KT
Ul File Number E361770
Pieces Per Reel (loose Part No.) NA
Pieces Per Reel (reeled Part No.) /
Pieces Per Reel (taped Part No.) /
Datenblatt Download Datenblatt
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
