Wire Grippers

  • 7 amperes

Packaging

  • Loose
  • Reeled
  • Small reeled
  • Taped
Article Number 1301
Extra Description 7 amperes
Mating Terminal Size 0.025" (0.64mm) square or 0.025" (0.64mm) round pin
Material Thickness / Type .008" (0.20mm) C51000 Phosphor Bronze
Standard Finish 100% Tin over Copper
Current Rating Ul 7 Amperes
Current Rating C-ul 7 Amperes
Feeder System Surf-Shooter SMT ™ Continuous Strip Feeder Standard 16mm Tape Feeder for PN 1301TH
Ul File Number E361770
Pieces Per Reel (loose Part No.) NA
Pieces Per Reel (reeled Part No.) /
Pieces Per Reel (taped Part No.) /
Datenblatt Download Datenblatt
Die Merkmale zwischen Varianten und Subvarianten sind unterschiedlich
