Compact round terminal block

Download product sheet

Number Of Poles

  • 2
  • 3
  • 5
Article Number THB.021.C1A THP.021.C1A THB.021.C3A
Number Of Contacts 2 2 2
Protection Degree IP20 IP20 IP20
Upper Temperature +125 °C +125 °C +125 °C
Lower Temperature -40 °C -40 °C -40 °C
Rated Voltage 450 450 450
Rated Current 32 A 17.5 A 24 A
Contact Terminal End barrier contact Piercing clip terminals max 1,5 mm² WP contact for cable section < 1,0 mm²
Terminals Screw Piercing Screw
Cable Section max 4,0 mm² 0,5 -1,5 mm² max 2,5 mm²
T Marking T125 °C T125 °C T125 °C
Tracking Index PTI 250 PTI 250 PTI 250
Terminal Block Housing PA66 GF UL94 V0 GWT 960°C black - brown PA66 GF UL94 V0 GWT 960°C black - brown PA66 GF UL94 V0 GWT 960°C black - brown
Contact Screw Terminals Brass nickel plated Brass nickel plated Brass nickel plated
Standard / Piercing Screws M3 steel zinc plated M3 steel zinc brass plated M3 steel zinc plated
Standards EN60998-1:2004 EN60998-2-1:2004 EN60998-1:2004 EN60998-2-1:2004 EN60998-1:2004 EN60998-2-1:2004
Characteristics differ between variants of a connector
