bulkhead mounting connector, angled, size 21.21, zinc, 1 lever stainless steel, 8p, RJ45

CJZAX 8 IA4

Add the desired housings and accessories to fully configure your connector.

Product Type	Data connection insert
Insert series	CJZ connectors
Number of contacts	8
Number of poles	8
Connection type	Data connection
Gender	Female
Size	21.21
Operation lower temperature	-40 °C
Operation upper temperature	120 °C
Colour	Grey

Max. rated current	2 A
Nominal rated voltage	50 V

Material insert	Zinc alloy
Inflammability class of insulation material acc. with UL94	V0
