hood, size 21.21, E-Xtreme alu, 2 pegs, 1xM20 top

MKAE V20

Add the desired accessories and standard inserts to fully configure your connector.

Enclosure type	Hood
Size	21.21
Enclosure series	E-Xtreme® C-TYPE
Closing type	With 2 pegs
Locking mechanism	Single locking lever
Protection degree	IP44 \| IP66 / IP67 / IP69
Ambient lower temperature	-40 °C
Ambient upper temperature	125 °C
Operation lower temperature	-40 °C
Operation upper temperature	125 °C
Cable entry type	top cable entry
Cable entry size	M20
Position cable feed	Top entry
Height	55 mm
Width	33.5 mm
Length	33.5 mm
Remark	FKM gasket (-40°C…+180°C) or silicone gasket (-60°C…+180°C)

Material housing	Die cast aluminium alloy
Coating housing	With epoxy-polyester thermosetting powder coating
Inflammability class of insulation material acc. with UL94	V2
