Ilme
- General
| Article Number | CFO 32 L* |
| Protection Degree | IP66 |
| Material Housing | Aluminium |
| Height | 94 mm |
| Remark | Enclosure without adaptor, threaded on the body, to be used only with a complete cable gland |
| Length | 93.5 |
| Extra Information |
Corrosion resistant UV resistant With interlocking device |
| Coating Housing | With powder coating |
| Required Inserts | CD 80P+PE; CDD 144P+PE; CDS 54P+PE; CSH 32P+PE; CNE-CSE 32P+PE; CCE 32P+PE; CSS 32P+PE; CQE 64P+PE; CMCE 12+4(aux)PE; CME 12+4(aux)P+PE; CMSH 12+4(aux)P+PE; CP 12P+PE; MIXO 4+4 modules; CDHS 54 P + PE |
| Locking Mechanism | Single locking lever |
| Operation Lower Temperature | -40 °C |
| Operation Upper Temperature | 125 °C |
| Position Cable Feed | Side entry |
| Width | 82.5 mm |
Eigenschappen verschillen tussen varianten en subvarianten
Accessoires
