Compact round terminal block

Download product sheet

Number Of Poles

  • 2
  • 2+2
  • 3
  • 3+3
  • 5
  • 6
Article Number THB.020.E1A THP.020.E1A THB.020.E3A
Number Of Contacts 2 2 2
Protection Degree IP00 IP00 IP00
Upper Temperature +125 °C +125 °C +125 °C
Lower Temperature -40 °C -40 °C -40 °C
Rated Voltage 450 450 450
Rated Current 32 A 17.5 A 24 A
Contact Terminal End barrier contact Piercing clip terminals max 1,5 mm² WP contact for cable section < 1,0 mm²
Terminals Screw Piercing Screw
Cable Section max 4,0 mm² 0,5 - 1,5 mm² max 2,5 mm²
T Marking T125 °C T125 °C T125 °C
Tracking Index PTI 250 PTI 250 PTI 250
Terminal Block Housing PA66 GF UL94 V0 GWT 960°C black - brown PA66 GF UL94 V0 GWT 960°C black - brown PA66 GF UL94 V0 GWT 960°C black - brown
Contact Screw Terminals Brass nickel plated Brass nickel plated Brass nickel plated
Screw M3 steel zinc brass plated M3 steel zinc plated M3 steel zinc brass plated
Standards EN60998-1:2004 EN60998-2-1:2004 EN60998-1:2004 EN60998-2-1:2004 EN60998-1:2004 EN60998-2-1:2004
Eigenschappen verschillen tussen varianten en subvarianten
