Screw Terminals / Binding Posts

1108

1108

Heeft u nog vragen over dit product?

Contacteer onze connector specialist

Vraag een offerte aan

Meer info over dit merk:

Screw Type

1/4" (6.35mm) x 6-32 Torx Head Screw
Stainless Steel Binding Head 1/4" (6.35mm) x 6-32

Article Number	1108-TORX*	1108-TORX-T
Remark	TORX = Torx screwdriver required	/
Packaging	Loose	Taped
Material Thickness / Type	0.032" (0.81mm) C26000 Brass	0.032" (0.81mm) C26000 Brass
Standard Finish	100% Tin over Copper	100% Tin over Copper
Current Rating	30 Amperes	30 Amperes
Screw Position	Inserted, Staked and Down	Inserted, Staked and Down
Pieces Per Reel (loose Part No.)	NA	/
Pieces Per Reel (taped Part No.)	/	500
Product sheet	Download product sheet	Download product sheet

Article Number	1108	1108-GRSC*
Remark	/	GRSC = green screw indicates it is a grounding screw
Packaging	Loose	Loose
Material Thickness / Type	0.032" (0.81mm) C26000 Brass	0.032" (0.81mm) C26000 Brass
Standard Finish	100% Tin over Copper	100% Tin over Copper
Current Rating	30 Amperes	30 Amperes
Screw Position	Inserted, Staked and Down	Inserted, Staked and Down
Pieces Per Reel (loose Part No.)	NA	NA
Pieces Per Reel (taped Part No.)	/	/
Product sheet	/	/

Eigenschappen verschillen tussen varianten en subvarianten
