Wire Grippers

  • 17 amperes

Packaging

  • Loose
  • Reeled
  • Small reeled
  • Taped
Article Number 1262 1262-19
Extra Description 17 amperes 17 amperes
Mating Terminal Size 0.025" (0.64mm) to 0.095" (2.41mm) round or square and 0.032" (0.81mm) x 0.110" Blade 0.025" (0.64mm) to 0.095" (2.41mm) round or square and 0.032" (0.81mm) x 0.110" Blade
Material Thickness / Type 0.010" (0.25mm) C51000 Phosphor Bronze 0.010" (0.25mm) C51000 Phosphor Bronze
Standard Finish 100% Tin over Copper 100% Tin over Copper
Current Rating Ul 17 Amperes 17 Amperes
Current Rating C-ul 17 Amperes 17 Amperes
Feeder System Surf-Shooter SMT ™ Continuous Strip Feeder Standard 24mm Tape Feeder for PN 1262T and PN 1262TH Surf-Shooter SMT ™ Continuous Strip Feeder Standard 24mm Tape Feeder for PN 1262T and PN 1262TH
Ul File Number E361770 E361770
Pieces Per Reel (loose Part No.) NA NA
Pieces Per Reel (reeled Part No.) / /
Pieces Per Reel (taped Part No.) / /
Pieces Per Reel (small Reel Part No.) / /
Product sheet Download product sheet Download product sheet
Eigenschappen verschillen tussen varianten en subvarianten
