Inserts 6+PE

  • Pins
Download product sheet

Contacts

  • Without
  • dip solder length 10 mm
  • dip solder length 17 mm
  • without (RAL2003 insert)
Number Of Contacts 6+PE
Termination Crimp/dip-solder (PCB)
Wire Section 0,34-1,5 mm²
Upper Temperature +125 °C
Lower Temperature -40 °C
Max. Contact Resistance 3 mΩ
Material Thermoplastic Polyamid PA 6/Fire protection class V-0
Required Crimp Contacts

"7.010.981.211"

Contact Diameter (mm) 1,25
Nominal Current 16 A
Nominal Voltage (degree Of Pollution 3) 630 V ~
Test Voltage 2500 V ~
Insulation Resistance >1010 MΩ
Eigenschappen verschillen tussen varianten en subvarianten
