Male round connector

  • Nickel plated metal nut + plastic body
Download product sheet

Number Of Poles

  • 3
  • 4
  • 5
  • 12
Article Number RCKM 00310 071
Number Of Contacts 3
Protection Degree IP67*
Upper Temperature +90 °C
Lower Temperature -25 °C
Cable Diameter 4-6,5 mm
Fixing Thread M12
Housing Material Plastic
Housing Oil Resistance Very good
Contact Material Optalloy
Max. Wire Section 0,75 mm²
Locking Nut Material Metal nickel plated
Voltage Vdc 1 to 250
Voltage Vac 1 to 250
Max. Currrent 4 A @40°C
Contact Gender M
Coding A
Cabling System Screw vite
Remark The protection degree level is guaranteed only when correctly assembled with Shield's couterpart
Eigenschappen verschillen tussen varianten en subvarianten
