Female round connector

  • PNP
Download product sheet

Number Of Poles

  • 4
Article Number RDMF 26100 374 3000
Number Of Contacts 4
Protection Degree IP65*
Upper Temperature +70 °C
Lower Temperature -40 °C
Housing Material TPU
Circuits PNP
Housing Oil Resistance Very good
Contact Material Golden over nickel plated CuZn
Locking Nut Material Brass nickel plated
Voltage Vdc 1 to 30
Max. Currrent 4 A @40°C
Housing Colour Transparent
Contact Gender F
Shielding not connected
Ground Pole No
Max. Number Wires 4
Wire Colour bn1, wh2, bu3, bk4
Coding A
Remark The protection degree level is guaranteed only when correctly assembled with Shield's couterpart
Eigenschappen verschillen tussen varianten en subvarianten
